SFH-MR

Automatic Self-Cleaning SFH models are supplied without protective coarse screen and suitable for low flow applications in industrial plants, local irrigation systems and domestic usage where water does not contain coarse particles.

SFH-MR

Product Description

Automatic Self-Cleaning SFH models are supplied without protective coarse screen and suitable for low flow applications in industrial plants, local irrigation systems and domestic usage where water does not contain coarse particles. We are using cookies to give you the best experience on our website.

Gallery

SFH-MR SFH-MR SFH-MR SFH-MR SFH-MR SFH-MR

Available Applications

Well Water
Irrigation

Technical Specifications

Body Material
AISI 304L, AISI 316L
Max. Operating Temperature
60°C / 90°C
Back-Flush Water Consumption
80 - 120 l / back-flush
Screen Material
AISI 316L
Headloss at Max. Flow Rate
0.2 bar
Fine Screen Range
10 - 3000 micron
Max. Operating Pressure
PN10 / PN16
Back-Flush Time
15 - 20 s
Control System
Electric
Min. Inlet Pressure Required During Back-Flush
2 bar
rpm of Cleaning Mechanism
Adjustable

Documents

SFH-MR Model Brochure
PDF

Technical Support

Have questions about this filter? Our expert team is ready to help you.

+90 (216) 499 80 01 info@filternox.com.tr
